What We Have
FOUNDRY - MACHINERY
Gas fired central melting furnace along with 2 electric holding furnaces would help to better plan & utilize production capacity efficiently
Melting Furnce
- Type: Gas Fire Hydraulic Tilting
- Capacity: 500 KG
- Technical Specification:
- Thermocouple: K Type
- Burner & Blower: 42-6 Burner & 5 HP (Continental Make)
- Crucible: TPC 587 (Vesuvius Make)
- Output: 120 MT/Month
- Make: SKR
- Number: 1
Melting / Holdig Furnce
- Type: Electric
- Capacity: 300 KG
- Technical Specification:
- Power Supply:36KW
- Crucible: BC 401 (Morgan Make)
- Power Control: Through Thyristor
- Temperature Control: Digital Controller (SKR Make)
- Heater: Kanthal A1 Coil
- Coil: Vertical Type
- Make: SKR
- Number: 2
GDC Tilting Machine
- Type: Tilting Open Type
- Technical Specification:
- Platen Size: 600x800 mm
- Tilting Degree: 0 to 90
- Maximum Die Weight: 1200 KG
- Power Pack- 7.5 HP with dual pump, 350 lts. tank capacity, oil cooler
- Cylinders: 6 Hydraulic
- Electro Hydraulic Proportional valve
- Make: Alucast Machines
- Number: 2
What We Have
FOUNDRY - MACHINERY
Yogiraj Alucast has in-house heat treatment and shot blasting facility which makes entire production process under one roof for better management
DE-Gassing Unit
- Type: Hoistable (Mobile Unit)
- Make: Foseco
- Salient Features:
- Nitrogen rotary degassing machine to ensure hydrogen free-molten metal
- Suitable for multiple furnaces with minimum floor space requirement
- Comes with PLC to ensure perfect degassing
- Additionally, Hydrogen gas index tester is used after degassing to ensure molten metal is gas-free
Heat Treatment Furnace
- Type: 45 kW Drop-Bottom Solution Annealing Furnace
- Make: Energy Systech
- Charge Weight: 500 KG
- Salient Features:
- Powerful air circulation for excellent temperature uniformity
- Mechanical Up/Down motion with “dunking” facility
- Sharp, quick quenching within 30 seconds
- Long-life vertical heaters
- Water level Indicator
Shot Blasting
- Type: Rotary hanger type, semiautomatic double door
- Make: Kelsons
- Capacity: 100 KG
- Technical Specifications:
- Cabin Size: 1250x1350 mm
- Bucket elevator: Electric motor with gearbox
- Shot feeding: Pneumatic
- Dust collector: Electric motor.
- Suitable for diverse product sizes
What We Have
Foundry - Equipments & Lab Facilities
In-house state of the art laboratory is an evidence of our quality consciousness. Total quality management system is strictly followed in every stage of the manufacturing process
Spectrometer
- Make: VAS
- Model: Silver Plus
- Salient Features:
- Fully digital, current- controlled source to ensure high accuracy, precision and stability
- Seamlessly scalable - with modular options on applications
- 30+ elements across bases including C, S, P, B, N etc.
- Detection limits of 50 ppm for C, S, P
- 2,000+ burns per cylinder
Belt Grinder & Bandsaw
- Type: Vertical Bandsaw
- Make: Maru & Jai
- Specifications:
- Size of tilting table: 18”x18” (Tilting-45)
- Max. cutting capacity: 8”Hx17” W
- Type: Double side abrasive belt grinder
- Make: Elmak
- Belt Size: 50 x2000 mm
Cutting Machine:
Grinder:
Testing Equipments
- Density Index Unit & Vacuum Analyzer (Make Foseco)
- Hardness Tester machine (Make Kelsons)
- 600 mm height gauge
- Micrometers
- Surface Plate 630x1000 mm (Make: Luthra)
- Vernier Height gauge (Make: Yuzuki), Depth gauge, Radius gauge, Bore dial gauge, Filler gauge, and others
What We Have
Machining Facilities
In-house machining facility reduces chances of damage/loss/quality issues; ensuring smooth supply of finished parts
VMC
- Make: ACE
- Model: MCV 450
- Control System: Fanuc
- Bed Size: 1000*400*400
- Spindle speed: 6000 rpm
CNC
- Make: Jyoti
- Model: DX 200 4B
- Spindle Power: 7/11
- Chuck Diameter: 250mm
- Turate Station: 8 No.
- Turate Length: 400 mm
OTHERS
- Radial Drill Machine
- Lathe Machine
- Surface Plate 800*1000
- Vernier Height gauge (Make: Yuzuki), Depth gauge, Radius gauge, Air guage, Bore dial gauge, Filler gauge
